How do I update Title Block properties like Text Height?
Change Properties of the title block using Block Editor.
Close Block Editor and save changes.
Type in "Insert" and select HyDrawTitleBlock from the list to reinsert the title
block with updated properties.
Delete the existing title block that came with the border.
Then, run the "Edit Title Block" command and enter the required details.
Now, the title block should show the data entered with new block properties.
